ETC (Electronic Throttle Control) System. Troubleshooting
Fail-Safe Mode
Item
Fail-Safe
ETC Motor
Throttle valve stuck at 5°
TPS
TPS 1 fault
ECM looks at TPS2
...
Inspection
1.
Turn the ignition switch OFF.
2.
Disconnect the RCV control solenoid valve connector.
3.
Measure resistance between the valve terminals 1
...
Description
Network ConfigurationThe Network of the SJB(Smart Junction Box) consists of Low
speed CAN as shown in the following figure.
Termination ResistorThe cluster has CAN termination resistor. It is p ...
